E60

Support Intel® 6th/7th/8th/9th CPU ；
Up to 2*Gigabit Ethernet；
Up to 4*USB3.0，4*USB2.0;
Support 1*M.2 2230 for WIFI+BT;
Support 1*full-size Mini PCIe for mSATA ;
Support DDR4 memory，max to 32GB;
Support HDMI+HDMI/VGA display;

Sample Application

Specifications Related Resources

System	CPU	Intel® 6th/7th/8th/9th CPU
	Chipset	B250/H310C
	BIOS	AMI BIOS
	GPU	Intel HD graphics
Display	HDMI	2 x HDMI（3840 x 2160@30Hz）
Display	VGA	1 x VGA（1920 x 1080@60Hz）
Extend	M.2	1 x M.2 2230 for WIFI+BT
Storage	M.2	1 x M.2 2280 for SSD（SATA ）
I/O Ports	Ethernet	Realtek 8111H;
	Ethernet	1x RJ45（optional 2 x RJ45）
	USB	4 x USB3.0 ，4 x USB2.0
	Audio	1 x 3.5mm mic， 1 x 3.5mm line out
	LED	1 x PWR LED
	COM	Optional 1 x RS232
Management		WoL
		Power On
		Watch dog
Power	Type	DC IN
	Voltage	19V
	Rate	65W / 90W
Environment	Operating temp	0 ℃ ~ 40 ℃
	Storage temp	-20 ℃ ~ 60 ℃
	Storagehum	95%@40 ℃（non-condensing）
Mechanical	Mount	Desktop & Mounting
	Dimensions	185.3mm x 184.2mm x 42.5mm
	Colour	Black
Certifications		CE/FCC(DoC) Class B，CCC
