Index Product Cloud Terminal V20

V20

Up to 2*GbE；
Support 6*USB（5*USB2.0+1*USB3.0);
Fanless Design;
Support EMMC5.0 Flash （optional） ;
1个*DDR3L SO-DIMM，max to 8GB;
Support HDMI+VGA;

Sample Application

Specifications Related Resources

System	CPU	IIntel® Celeron® Processor J1800/J1900
	Chipset	SOC
	BIOS	AMI BIOS
	GPU	Intel® HD Graphics
Display	HDMI	1 x HDMI(Max.1920 x 1080@60Hz)
Display	VGA	1 x VGA(Max. 1920 x 1080 @ 60Hz)
Extend	Mini PCIe	1 x full-size Mini-PCIe for mSATA
Extend	Mini PCIe	1 x full-size Mini-PCIe for WiFi/BT/3G/4G
存储	mSATA	Optional EMMC
Memory		DDR3L-1333，Max. 8GB，1 xSODIMM
I/O Ports	Ethernet	Realtek 8111G，2 x RJ45


	USB	1 x USB 3.0， 5 x USB 2.0
	Audio	1 x 3.5mm Mic， 1 x 3.5mm Line out
Management		WOL
		Power on RTC
		Power on
Power	Type	DC IN
	Voltage	12V~19V
	Rate	30W
Environment	Operating temp	0 ℃ ~ 40 ℃
	Storage temp	-20 ℃ ~ 60 ℃
	Storage Hu	95%@40 ℃（non-condensing）
Mechanical	Mounting	Desktop & Mounting
	Dimensions	170mm x 120mm x36mm
	Colour	Black
Certifications		CE/FCC(DoC) Class B，CCC
